FTD-GG GA GG25 EPDM PN10

Model: With limit switch Material body: Steel EN 1.0619
Connection: Flanged PN16/40 Material disc: St.St. EN 1.4408 check PDF
Temperature: Fluid -20°C / +200°C Material seat: PTFE filled with 15 % glass
Pressure: up to DN50 PN40 > PN16 see pdf Steam: 11 bars maximum
Limit switch
IP code: IP 67 Temperature: Ambiant -20°C / +80°C
Power: 250V AC-5A 2 SPDT Silver Plated Model: SF 01200
Body material: Aluminium Mounting bridge: Stainless steel
Dome: Polycarbonate Coating: Polyester paint
Click to add this item to cart.

See also different:

FTD-G with Lever UFT -EPM
FTD-G with Lever UFT -EPM

Model: Knife gate valve Material body: Stainless steel CF8M 316 Actuating: Lever operated Material wedge: Stainless steel CF8M 316 Connection: Between flanges PN10 Material seat: EPM Temperature: -15 ° C / + 110 ° C Pressure: DN50 up to DN200 [...]

Ductile iron PN10 | EN-GJS-500-7 FTD-GD
Ductile iron PN10 | EN-GJS-500-7 FTD-GD

Model: Bidirectional Material body: EN-GJS-500 Connection: Between flanges PN10 Material gate: Stainless steel AISI 304 Pressure: 10 bar > see PDF Material seat: Natural rubber Temperature: 0°C  +90°C

FTD-GD Zt.Zt.345-EPM
FTD-GD Zt.Zt.345-EPM

Model: Knife gate valve Material body: Stainless steel CF8M 316 Actuating: Handwheel operated Material wedge: Stainless steel 316 Connection: Between flanges PN10 Material seat: EPDM Temperature: -20 ° C / + 130 ° C Pressure: DN50 up to DN200 [...]
